Welding equipment

Welding technology - Now it's time to weld!

Professional and hobby welders alike will find welding equipment, the appropriate welding consumables, a wide range of accessories as well as extraction technology and welding robots for automation. When it comes to state-of-the-art welding technology for your mobile or stationary welding tasks, we have a solution for every problem - from advice, demonstration and sales to UVV inspections, calibration and repair or maintenance of your welding equipment. Weld steel, stainless steel and aluminum effortlessly and with high quality using our gas-shielded arc welding systems. Thanks to the MIG/MAG and TIG welding machines, plasma cutters and torches from renowned brands such as Lorch, TEKA, Siegmund, Esab, Nederman and Trafimet, you can optimize your processes with state-of-the-art technology

To the products

Unsere Top-Produkte

UVV inspection of arc welding equipment

UVV inspection in accordance with DIN EN 60974-4, VDE 0544-4 of arc welding equipment

Testing of arc welding equipment in accordance with DIN EN 60974-4 Commercial welding and cutting equipment is subject to the statutory regulation DGUV 3 (formerly BGV A 3). This states that the equipment should be inspected at least once a year. In some cases, this inspection period can also be shortened if there is a high level of stress and danger. The risk assessment determines in advance which test period applies in each individual case.</p

Our specialists carry out the testing of arc welding equipment in accordance with DIN EN 60974-4 at your premises or at WEMAG. This means that your equipment is once again legally compliant and at the same time this testing and inspection increases the value retention of your systems and minimizes possible downtimes

What we need from you:

  • Machine list with the number of welding machines to be tested
  • Workplace for testing with CEE 16A or 32A power connection

Your benefits of regular testing and maintenance:

  • High availability of your welding equipment
  • Maintaining the value of your systems is extended
  • Significantly fewer extensive and expensive repairs
  • Rarely any consequential damage due to soiling such as sucked-in swarf and sanding dust
  • Maintained inventory list of your welding equipment
  • Safety in the event of accidents with the BG and insurer
  • We carry out minor repairs immediately after consultation

Audit scope

  • Visual inspection
  • Internal cleaning of the welding system
  • Overhaul of the wire feed system
  • &overhaul of the water cooling system
  • &check of the welding burner system
  • Testing the overall system function
  • Safety inspection with measurement of...
    • ... Insulation resistance primary against housing
    • ... Insulation resistance secondary to housing
    • ... Insulation resistance primary to secondary
    • ... Contact current
    • ... Protective conductor current
    • ... Open-circuit voltage
  • Creation of a standard-compliant test report and affixing of a test sticker to the device

Our service for you:

  • Recurring inspection and testing
  • Production of test reports and documentation
  • Carrying out minor repairs after consultation
Request examination

Calibration and validation of arc welding equipment in accordance with DIN EN IEC 60974-14

Enquire now!

The standards EN 1090, EN 729-2 and DIN EN ISO 9001 ff. require the regular performance of calibration and validation of welding equipment

Our certified welding technicians will calibrate your manual metal arc, TIG and MIG/MAG welding equipment in accordance with the applicable standards. After calibration, which we are happy to carry out on your premises, you will receive a test report and a test badge.

All arc welding equipment in metalworking companies that are certified according to EN 1090 or DIN EN ISO 9001 ff. must be calibrated regularly. Calibration and validation of the welding technology in your company is also a prerequisite for qualified documentation in quality management. This also serves as proof for the employers' liability insurance association and insurance company in the event of damage.

Instructions for use in accordance with TRBS 1201 for oxyfuel welding systems

„The contractor shall ensure that dry point of use templates are tested at least once a year by an expert for safety against gas leakage and for tightness.“

Our service for you:

  • Calibration and validation by our certified testers
  • Production of test reports and documentation
Request examination

Professional welding results thanks to automation

A shortage of personnel is a big issue for you?

We provide a remedy with robotic solutions - whether free-standing robots (cobots) or complete welding cells. Get professional support from cobots that reliably complete your welding tasks with high-quality welding shafts

to welding robots

Welding workshop

We repair your defective welding equipment!

We at WEMAG have our own welding workshops. One of them is located in Fulda, at the headquarters site, the other in Kassel – and takes care of the repair, maintenance and servicing of your small and large machines – these are welding machines, plasma cutters, torches and welding robots

Easy handling

  • You bring your defective device to one of our specialist welding workshops or...
  • We collect the device from you or...
  • We repair the device directly at your premises if possible

Before each repair, our specialists will get an idea of the possible damage and then inform you of the costs incurred.

Contact us and arrange an appointment directly.

Make an appointment now!

Your specialist consultants for welding technology

An excerpt from our brands

FORMHAND
MILTEX

Dienstleistung
ALKI
TESA classic

ALMAR

WESERGOLD

RAINBOW
TYCHEM
RAPID
VSM
ELLEHAMMER

Welding technology

Metal components are joined together using a welding process. A welding filler material, such as welding wire, is usually used for this. For complex welding work, welding robots are often used in industry to produce clean welds.
